HH-T-6
Classification:
Request Quote
Details Introduction
01. The operating table is equipped with a back plate adjusting hand wheel and a leg plate operating hand wheel on the left and right sides. No matter on the left or right side of the operating table, the positions of the back plate and the leg plate can be operated;
02. The right side of the operating table is equipped with a roll adjustment crank for controlling the left or right tilt of the operating table and a lumbar plate adjustment crank for controlling the lumbar plate action;
03. The anteroposterior adjustment handle for operating the operating table to lean forward or backward is installed on the right side of the operating table, and the handle can also be removed and replaced on the left side of the operating table for operation;
04. The lifting of the operating table is adjusted by the oil pump structure. The imported hydraulic ram is used. When leaving the factory, the oil in the oil pump is pumped out and installed in the barrel. The oil pump cannot be raised. The user needs to slowly add the oil in the oil barrel into the oil pump from the funnel (the oil outlet pipe and funnel can be taken after refueling). When the table rises, the oil pump foot can be stepped on continuously, and the table will automatically stop rising when it rises to the highest point. When the table is lowered, the oil pump can be stepped on to the lowest position, and the table can be lowered slowly;
05. The bed chassis is equipped with rotating casters, easy to move. There is a landing mechanism to operate, the bed is fixed or moved, and the same foot is used. When the landing foot is stepped down, the rotating caster in the chassis is lowered, the chassis is lifted up, the bed can be pushed, the foot is lifted, and the bed is fixed to the ground.
|
Project |
Description |
Remarks |
|
Table size mm |
Total length ≥ 2100, width ≥ 480 |
No side rail |
|
Table height mm |
Minimum ≤ 800, maximum ≥ 1045 |
Mattress not included |
|
Table Action Parameters |
The head plate can be folded up ≥ 90 °, folded down ≥ 90 °, and can be extended and detachable |
|
|
Back plate folded up ≥ 75 °, folded down ≥ 20 ° |
|
|
|
Table front inclination ≥ 35 °, back inclination ≥ 20 ° |
|
|
|
Table left≥ 20 °, right≥ 20 ° |
|
|
|
Waist bridge lifting |
≥ 120 mm |
|
|
Leg plate folding angle |
Fold down ≥ 90 ° |
|
Keywords: operating bed, electric operating bed
